Cylinder activation is fingertip controlled, the more the hand lever is engaged the more the ram movement is accelerated. This allows the operator to control the proper speed for the task.
All hydraulic and mechanical parts are standard in the industry, and available throughout North America.
click on picture to enlarge
Standard features
Cylinder activation is fingertip controlled, the more the hand lever is engaged the more the ram movement is accelerated. This allows the operator to control the proper speed for the task.
All hydraulic and mechanical parts are standard in the industry, and available throughout North America.
Low pressure hydraulic system maintains lower oil temperatures, resulting in higher efficiency and safer operation.
We use large bore cylinders averaging 3,800 P.S.I. maximum pressure throughout our complete line of H Frame Presses. Most other manufactures use small bore cylinders
at 700 bar equal to 10,152 P.S.I. operating pressure.
At RK Machinery operator safety is our number one concern.
Hydraulic power pack conveniently located up and out of the way.
All hydraulic and mechanical parts are standard in the industry, and available throughout North America.
Self-locking table design eliminates lateral movement.
Standard feature on all H Frame Press models.
The more pressure that you apply to the workpiece, the more rigid the table and frame become.
Open sides to facilitate work on long pieces.
Flat ram nose can be easily changed to allow the user to adapt the press to a specific job.
Double-acting cylinder permits pulling as well as pressing ram action.
Hydraulic power-lift for vertical displacement of table.
Double-acting cylinder permits pulling as well as pressing ram action.
Front safety guard for operator protection (optional).
The head consists of three 2.000” hardened pins per leg. These pins are positioned into the leg and head then welded in place and ground even. When the press is painted they are not even visible.
Do the math
Tensile strength = AREA x PSI x No. of Pins.
3.14 x D2 ÷ 4 x 100,000 lbs. Per SQ. IN. x 12 Pins = 3,768,000 lbs. 1,884 Tons.
V BLOCKS matched pair (optional).
Flat ram nose can be easily changed to allow the user to adapt the press to a specific job.
Options available
Stop / Start c/w emergency stop button, wired direct to motor. Model may vary depending on the voltage.
Pressing plate for a Hydraulic press. Table is precision milled.
Hydraulic Press V Blocks, matched pair.
Front safety guard for operator protection. Safety guard can be removed within a few seconds if necessary.
Adjustable stroke control c/w foot pedal-electric solenoid valve, speed control and electric control panel.
Operation of the safety kit: When any of the four guards are opened, the press will automatically go to jog mode "low pressure", unless the operator turns the key to the “on” position which will enable the operator to use the press at full pressure with the guards open.
Industrial side lights for better visibility.
Foot pedal-electric solenoid valve for hands-free operation, c/w electric control panel
Handheld wireless remote control with variable speed on all axis, permits the operator to move freely around the press.
